2016 Explorer Limited power gate won't close


ceege

New Member
Joined
July 26, 2017
Messages
3
Reaction score
0
City, State
Regina, SK
Year, Model & Trim Level
2016 Explorer Limited
Hi all,

I have a 2016 Explorer and a few weeks ago our gate started acting up. Every time any method is used to open the gate (keyfob, door button, dash button or the kicking motion thing), it opens faster than it used to and only about 1/3 to 1/2 of the way. Pushing anything again will continue to make it open more. Even when it's at the very top, it will still try to go up instead of down.

I've tried disconnecting the battery and resetting the height, but neither made a difference.

Closing and opening the gate seems smooth and where ever the gate is placed it stays. From what I've read in other threads sometimes a busted actuator can cause the motor to misbehave, but I don't think that's my issue. Are there any sensors used here that could be the problem (not telling the door to go down)? Or is this just the motor that's messed up? Or am I missing something else?

Thanks in advance!



Join the Elite Explorers for $20 per year. Gets rid of the ads! New $5 per month "try out" option.

Explorer Forum has probably saved you that much already, and will continue to save you money as you learn how to diagnose fix problems yourself and learn which modifications work without having to experiment on your own. Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private Conversations, and more. Join Today. Your support is greatly appreciated.




peterk9

Staff member
Moderator
Elite Explorer
Joined
December 28, 2010
Messages
28,341
Reaction score
1,726
City, State
Russell, Ontario (Ottawa area)
Year, Model & Trim Level
2020 Aviator Reserve
Callsign
VE3
Welcome to the Forum.:wave:
The pre 2016 Manuals had a Liftgate Reset procedure. Not sure if it is valid on 2016+ Explorers.
Resetting the Power Liftgate
The liftgate may not operate properly and you may need to reset it if any
of these conditions occur:
• A low voltage or dead battery
• A disconnected battery
• You manually close the liftgate and leave it ajar (unlatched)
To reset the power liftgate:
1. Disconnect the battery for 20 seconds then, reconnect the battery.
2. Manually close and fully latch the liftgate.
3. Power open the liftgate by using the transmitter or the instrument
panel control button.


Do you get any tones when the 'gate' opens or tries to close? The system is equipped with "obstacle detection". BTW, the liftgate actuator is the motor. There is also a Left and Right "pinch sensor" although I've not read where anyone had to replace those. Several have members have replaced to "actuator".
Lift Gate for 2016 Ford Explorer | Auto Nation Ford White Bear Lake
2016-2019 Ford Actuator GB5Z-14B351-A | Auto Nation Ford White Bear Lake

Peter





ceege

New Member
Joined
July 26, 2017
Messages
3
Reaction score
0
City, State
Regina, SK
Year, Model & Trim Level
2016 Explorer Limited
The manual talks about disconnecting the battery for 20 seconds (which I've done) and you can hold the button on the door to reset the max height (which I've also done). I get the 3 tones every time you push the button.





peterk9

Staff member
Moderator
Elite Explorer
Joined
December 28, 2010
Messages
28,341
Reaction score
1,726
City, State
Russell, Ontario (Ottawa area)
Year, Model & Trim Level
2020 Aviator Reserve
Callsign
VE3
The 3 tones when closing indicates that all is good. There should not be any tones when opening. Is this issue happening all the time or only occasionally? So if I understand correctly, there is no way to close it electronically. Is that right? If so, it could very well be an issue with the actuator. I'm hoping someone else will jump in here as well.

Peter





ceege

New Member
Joined
July 26, 2017
Messages
3
Reaction score
0
City, State
Regina, SK
Year, Model & Trim Level
2016 Explorer Limited
Yes it happens all the time. There is no way to close electronically. Interesting about the tones - I could have sworn it made noise when opening and closing. :dunno:





peterk9

Staff member
Moderator
Elite Explorer
Joined
December 28, 2010
Messages
28,341
Reaction score
1,726
City, State
Russell, Ontario (Ottawa area)
Year, Model & Trim Level
2020 Aviator Reserve
Callsign
VE3
Yes it happens all the time. There is no way to close electronically. Interesting about the tones - I could have sworn it made noise when opening and closing. :dunno:
Anything different than 3 tones/chimes when closing, is an indication of a problem.

Peter
