intermittent clunk or thud in 4x4

vroomzoomboom

Elite Canuck STOCK SUCKS!
Elite Explorer
Joined
January 22, 2007
Messages
9,988
Reaction score
1,527
City, State
selkirk, manitoba
Year, Model & Trim Level
98 supercharged 347 sport
i have posted this in a ranger message board, figured i would also put it up here.

i have a 07 level 2 (has 33's on it if this will count) with around 260kms (161 miles) on it. starting this winter, i have noticed a cluck or thud when the truck is in 4x4. it feels like its from the front end, or front side of the truck, and not the back. the other problem is its intermittent. it will happen when being driven a distance of around one km, or around a 1/2 mile no matter what speed. also the faster you are travelling, the harder the clunk or thud. the best way i can describe it is it feels like hitting a joining point on the road that is separated. it will only do it in 4x4 and not 2wd. the front u joint was replace around 2 years ago, as well as the passengers front cv axle. the drives axle was also replaced in the spring if i remember right, or last year. there is no grind sound, and its not popping out of 4x4 either.
thanks in advance.




Join the Elite Explorers for $20 each year.
Elite Explorer members see no advertisements, no banner ads, no double underlined links,.
Add an avatar, upload photo attachments, and more!
.





RangerX

Elite Ranger
Staff member
Moderator
Elite Explorer
Joined
July 14, 1999
Messages
10,418
Reaction score
648
City, State
Omao, Kauai
Year, Model & Trim Level
'93 Ranger XLT 4X4
I’m not familiar enough with the IFS front axle, but there must be more than one u joint. You say you replaced the u joint, did mean joints plural? Because u joint would be my first thought on this. Second would be hubs. Or possibly front driveshaft u joint?
You’ve probably thought of all this but just throwing ideas out there...







Turdle

The Lowrider is a little higher
Staff member
Moderator
Elite Explorer
Joined
June 16, 2003
Messages
30,539
Reaction score
2,302
City, State
Humboldt, KS
Year, Model & Trim Level
2000 Mounty
Check the front diff torque bracket bushing. Try to pry the bracket down from frame. If you can move that at all, the bushing is loose, allowing a bind.







Turdle

The Lowrider is a little higher
Staff member
Moderator
Elite Explorer
Joined
June 16, 2003
Messages
30,539
Reaction score
2,302
City, State
Humboldt, KS
Year, Model & Trim Level
2000 Mounty







vroomzoomboom

Elite Canuck STOCK SUCKS!
Elite Explorer
Joined
January 22, 2007
Messages
9,988
Reaction score
1,527
City, State
selkirk, manitoba
Year, Model & Trim Level
98 supercharged 347 sport
I’m not familiar enough with the IFS front axle, but there must be more than one u joint. You say you replaced the u joint, did mean joints plural? Because u joint would be my first thought on this. Second would be hubs. Or possibly front driveshaft u joint?
You’ve probably thought of all this but just throwing ideas out there...

the front end on this is pretty much identical to the 2nd gen ex's. the front drive shaft has a u joint on the diff side, and a cv at the transfercase side.
hubs possibly. i did both sides around 3 something years ago, and replaced them with either skf or timken so they werent cheap ones. i also dont really travel far to often with it (work is 5 mins away) so there isnt too many miles on the parts i replaced.


thanks for the link jon. i think i even remember when you first posted this and the link to the video was still alive. i will check that bushing and see what shape its in. the clunk seems to be on the drivers side but hard to say for sure, and i can also feel something around my feet, but i wrote it off to the body life shifting a tiny bit do to the cold.
ill look it over tomorrow and report back.







vroomzoomboom

Elite Canuck STOCK SUCKS!
Elite Explorer
Joined
January 22, 2007
Messages
9,988
Reaction score
1,527
City, State
selkirk, manitoba
Year, Model & Trim Level
98 supercharged 347 sport
got around to seeing whats what with the front diff. crawled under it yesterday to see if that bushing would move with a pry bar. rock solid, to very little movement. while i was there, i also wanted to check the diff fluid. it was down a little but not much at all. but then i happen to look at the front cv axle on the drivers side.






it looks like its floating around and wanting to pull out of the diff. i think what is happening is the cv's are binding up on themselves. i will have to see if i can force it back in with everything together. if not, i will have to pull the axle out and see if the lock ring has broken or why it is not holding.







Turdle

The Lowrider is a little higher
Staff member
Moderator
Elite Explorer
Joined
June 16, 2003
Messages
30,539
Reaction score
2,302
City, State
Humboldt, KS
Year, Model & Trim Level
2000 Mounty
I don't feel like the clip is going to keep it from walking out like that. You might have a worn cv axle.

Edit
See what the cvs do while spinning wheels at full droop, both front wheels in air on jackstands. Do this while also checking steering angle.







vroomzoomboom

Elite Canuck STOCK SUCKS!
Elite Explorer
Joined
January 22, 2007
Messages
9,988
Reaction score
1,527
City, State
selkirk, manitoba
Year, Model & Trim Level
98 supercharged 347 sport
yesterday was nice out (hell, its been nice all winter, hope i didnt just jinx it) so i pulled everything apart to see what was going on. i was also sure that axle was fairly new as well. the verdict, the clip was missing from the end of the axle. i was also right as well, that axle is new because there was zero rust on the nut and threads. looks like im making a order to rock auto













vroomzoomboom

Elite Canuck STOCK SUCKS!
Elite Explorer
Joined
January 22, 2007
Messages
9,988
Reaction score
1,527
City, State
selkirk, manitoba
Year, Model & Trim Level
98 supercharged 347 sport
You just need a clip?
i might? the thing that got me to also thinking replace it even if that axle isnt that old is did i do any damage to it? after all, the angles have changed with it trying to walk out of the diff, and if that is whats binding up it may have worn everything out inside.







vroomzoomboom

Elite Canuck STOCK SUCKS!
Elite Explorer
Joined
January 22, 2007
Messages
9,988
Reaction score
1,527
City, State
selkirk, manitoba
Year, Model & Trim Level
98 supercharged 347 sport
today i had a chance to go for a ride to see if its still acting up. well, thats 80 bucks i will never get back. still doing its thing :angryfire:
