mileage display not very bright

wickedme45

New Member
Joined
December 2, 2007
Messages
25
Reaction score
0
Year, Model & Trim Level
02 XLT
is there a fix for the cluster? some times its fine sometimes you cant see it mostly during the day

Join the Elite Explorers for $20.

Explorer Forum has probably saved you that much already, and will continue to save you money as you learn how to diagnose fix problems yourself and learn which modifications work without having to experiment on your own. Elite Explorer members see practically no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private Conversations, and more. Join Today. Your support is greatly appreciated.


E.B. Cornburner

Well-Known Member
Joined
April 20, 2007
Messages
1,137
Reaction score
4
City, State
Oshkosh, WI
Year, Model & Trim Level
2004 Eddie Bauer
The fix (according to Ford) is replacing it. There was a poor connection on the board somewhere. Most common to see in 2002 models.

Last edited:

Denny347

New Member
Joined
June 16, 2007
Messages
37
Reaction score
0
City, State
Indianapolis,IN
Year, Model & Trim Level
2002 XLT
Same problem here. I finally tore into it this evening. Took me about 1.5 hrs to fix it. would only take me about 45 min if I had to do it again. There are 4 resistors that are on the cluster board that looked bad. I re-soldered them since at least one joint looked weak. What do you know, it is back to original brightness. The bad joint was creating a lot of resistance and as a result a lot of heat. Replacing the solder should correct that. We'll see how long it will last. Here are a few pics I took. Take the cluster out, unscrew the black panel on the rear exposing the circuit board. the board just lifts off the rest of the cluster but a ribbon cable is still connected to it. You don't really need to remove the circuit board but I did trying to find the bad area but now I know I did not need to waste my time doing that. I also took the opportunity to remove the clear plastic and clean up the dust from inside the cluster. Here are a few pics. If it goes out again I will probably buy new resistors and try replacing those...what do I have to lose by doing that.



The circles are the back sides of the resistors. The arrow is the joint that I think was the problem. I replaced most of the solder joints anyway, just to be safe.

Last edited:
W

wd400

Great post! I just took off my cluster to bring it to a friend who is a better welder than me. Can I drive my truck like that for a few day whitout broking or shorting anything????


Denny347

New Member
Joined
June 16, 2007
Messages
37
Reaction score
0
City, State
Indianapolis,IN
Year, Model & Trim Level
2002 XLT
Great post! I just took off my cluster to bring it to a friend who is a better welder than me. Can I drive my truck like that for a few day whitout broking or shorting anything????
I'm not sure that the truck will start without the cluster installed. I'm pretty sure it will not.


wickedme45

New Member
Joined
December 2, 2007
Messages
25
Reaction score
0
Year, Model & Trim Level
02 XLT
i resoldered the joints and all is well so far thanks

W

wd400

We change the resistors. Work like new. I'l give some feedback in a few month.


Denny347

New Member
Joined
June 16, 2007
Messages
37
Reaction score
0
City, State
Indianapolis,IN
Year, Model & Trim Level
2002 XLT
Well, just got home from a 2,000 mi road trip and no problems. Even in 100+ heat they display looked bright. I'm happy. As a bonus, I cleaned all the dust out of the cluster when I pulled it out so it looks new.


2002 XLS X

New Member
Joined
July 14, 2009
Messages
14
Reaction score
0
City, State
Newport, MI
Year, Model & Trim Level
'02 XLS
hi, i have a 02 XLS and the 4x4 lights on the dash dont work or the push button 4x4 lights...is there a way to fix this so they work or do i have to replace the whole cluster...


wth

New Member
Joined
March 18, 2009
Messages
17
Reaction score
0
Great post & luv the pics. You would think that Ford would have learned their lesson, since this reminds me of the old "resistor/power supply" problem in those old '97 - '01 dual tape/cd disc radios, where the radio display went dead. And my '02 has a dim display with headlights off during the day.


BigRondo

USMC 1371
Elite Explorer
Moderator Emeritus
Joined
February 15, 2010
Messages
7,886
Reaction score
10
City, State
Worcester, MA
Year, Model & Trim Level
2002 XLT V6 4x4
Just did this today. Awesome! I love having my LED Display working again. Thanks Denny347, for the pics and the procedure for re-soldering the cold joints. :thumbsup::thumbsup: I followed the instructions in this thread for removing the instrument cluster, thanks XtremeRanger for the awesome write up!: http://www.explorerforum.com/forums/showthread.php?t=218636


Denny347

New Member
Joined
June 16, 2007
Messages
37
Reaction score
0
City, State
Indianapolis,IN
Year, Model & Trim Level
2002 XLT
No problem. Just fyi, the readout is still just as bright 2 years later.


BigRondo

USMC 1371
Elite Explorer
Moderator Emeritus
Joined
February 15, 2010
Messages
7,886
Reaction score
10
City, State
Worcester, MA
Year, Model & Trim Level
2002 XLT V6 4x4
No problem. Just fyi, the readout is still just as bright 2 years later.
I didn't have a problem with it being too dim. My problem was that it would work intermittently, some times it wouldn't even display, most of the time when it was displayed it wouldn't update the mileage & compass. It's nice to have it working like it should. Thanks again. ;)


34Ford

Member
Joined
May 30, 2007
Messages
89
Reaction score
0
City, State
North Carolina
Year, Model & Trim Level
2002 EB 4.6
Thanks Denny for your post. I wished I had looked at those resistors when I had all that tore out the two times looking for a problem.


BigRondo

USMC 1371
Elite Explorer
Moderator Emeritus
Joined
February 15, 2010
Messages
7,886
Reaction score
10
City, State
Worcester, MA
Year, Model & Trim Level
2002 XLT V6 4x4
Thanks Denny for your post. I wished I had looked at those resistors when I had all that tore out the two times looking for a problem.
The area around the 4 resistors on my cluster looked exactly like the ones in the picture by Denny. I knew that was my problem. I re-soldered the resistors and so-far-so-good, knock on wood. I got the 30 watt pencil soldering iron at walmart for $10. It came with the rosin core solder. Got the Ex in February and had been meaning to fix the display since then. It was driving me nuts. It's nice to have it working properly.


34Ford

Member
Joined
May 30, 2007
Messages
89
Reaction score
0
City, State
North Carolina
Year, Model & Trim Level
2002 EB 4.6
Dammit! Would have been nice if the year model was posted in here on these clusters.:mad:

I tore all that out for nothing.

Well here is how a '02 is made.



D Hook

Elite Explorer
Joined
October 10, 2010
Messages
970
Reaction score
21
City, State
Omaha, NE
Year, Model & Trim Level
06 Explorer Limited V-8
I thought these were all '02 clusters. Yours looks different.


BigRondo

USMC 1371
Elite Explorer
Moderator Emeritus
Joined
February 15, 2010
Messages
7,886
Reaction score
10
City, State
Worcester, MA
Year, Model & Trim Level
2002 XLT V6 4x4
Dammit! Would have been nice if the year model was posted in here on these clusters.:mad:

I tore all that out for nothing.

Well here is how a '02 is made.

I disagree. I have an '02 and mine looks exactly like Denny347's picture in post #3. You don't happen to have a Sport Trac or a Sport, do you? This is the '02-'05 Explorer - Mountaineer Forum. Sport Trac and Sport use the 1995-2001 forum. :dunno:


34Ford

Member
Joined
May 30, 2007
Messages
89
Reaction score
0
City, State
North Carolina
Year, Model & Trim Level
2002 EB 4.6
What do you mean its not out of a '02?

Its in this ya goofball.

Join the Elite Explorers for $20.

Explorer Forum has probably saved you that much already, and will continue to save you money as you learn how to diagnose fix problems yourself and learn which modifications work without having to experiment on your own. Elite Explorer members see practically no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private Conversations, and more. Join Today. Your support is greatly appreciated.


BigRondo

USMC 1371
Elite Explorer
Moderator Emeritus
Joined
February 15, 2010
Messages
7,886
Reaction score
10
City, State
Worcester, MA
Year, Model & Trim Level
2002 XLT V6 4x4
What do you mean its not out of a '02?

Its in this ya goofball.
I think you misunderstood. I didn't say that you don't have an '02. I was asking if you had a sport trac or a sport since these are different from the 4-doors. I have an '02 and my cluster is exactly like the picture in post #3. That's all. No harm intended.
