Rear differential - seal replacement

SoNic67

Explorer Addict
Joined
January 24, 2010
Messages
3,051
Reaction score
15
City, State
Newport News, VA
Year, Model & Trim Level
2001 V8 (Eddie Bauer) AWD
<

Join the Elite Explorers $20 Gets rid of the ads!

Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private conversations, and more. Join Today. Your support is greatly appreciated.




Rick

Pumpkin Pilot
Staff member
Admin
Elite Explorer
Joined
February 8, 1999
Messages
33,453
Reaction score
1,786
City, State
Wayoutin, Aridzona
Year, Model & Trim Level
'93 XL Pumpkin Edition
Callsign
AB7FH
<



SoNic67

Explorer Addict
Joined
January 24, 2010
Messages
3,051
Reaction score
15
City, State
Newport News, VA
Year, Model & Trim Level
2001 V8 (Eddie Bauer) AWD
<



koda2000

Explorer Addict
Joined
September 2, 2011
Messages
13,852
Reaction score
1,502
Year, Model & Trim Level
x
The thing with removing the pinion nut is to return it to the precise location it was removed from. To do this you can make a mark on the nut and the housing with a punch and, using your torque wrench, approximate the tightness of the nut while removing.

Doing this returns the pinion gear teeth to the same depth in relationship to the ring gear teeth, this allows the wear pattern to remain correct. If you install a new crush sleeve, the correct way to measure the correct pinion gear depth and tightness is to use an inch-pound torque wrench and (with the ring gear/spool removed) set the drag on the pinion to something like 12-16 inch pounds. Then you still need to check the pinion/ring gear engagement with a yellow grease-like compound. It's just a lot easier for the DIY'er to just return the pinion nut to the same location.

You wont need a new flange unless your old seal has worn a grove in your original flange. Plus, unless the new flange is the identical measurement to your original flange, using it and the new nut will not allow you to achieve the same pinion nut tightness.

I have to do this job on by '00 XLT soon and I plan to just buy a new seal and mark the pinion nut. I've done this this way in the past w/out a problem.

<



1998Exp

Explorer Addict
Joined
December 5, 2010
Messages
1,297
Reaction score
162
City, State
Seattle WA
Year, Model & Trim Level
98 Limited V8 AWD
As far as I know, preload and pinion depth are two separate things. The preload is for the bearings, not for the pinion teeth engagement. Your (simplified) procedure is for former. Pinion depth should not be affected when only the seal is replaced.

The thing with removing the pinion nut is to return it to the precise location it was removed from. To do this you can make a mark on the nut and the housing with a punch and, using your torque wrench, approximate the tightness of the nut while removing.

Doing this returns the pinion gear teeth to the same depth in relationship to the ring gear teeth, this allows the wear pattern to remain correct. If you install a new crush sleeve, the correct way to measure the correct pinion gear depth and tightness is to use an inch-pound torque wrench and (with the ring gear/spool removed) set the drag on the pinion to something like 12-16 inch pounds. Then you still need to check the pinion/ring gear engagement with a yellow grease-like compound. It's just a lot easier for the DIY'er to just return the pinion nut to the same location.

<



crunchie_frog

Well-Known Member
Joined
June 19, 2010
Messages
632
Reaction score
46
City, State
Johnson City, TN
Year, Model & Trim Level
Multiple 99-00 5.0 AWD
Thanks. Another question: Why does Dorman sell a kit with the seal, nut and the flange?
http://shop.advanceautoparts.com/p/...luding-seal-and-pinion-nut-697-507/10097714-P
What can go wrong with the flange?

I have done 3 of these for these vehicles. All of them had some surface wear on the flange where the seal was. I used the Dorman kit for all of them and have had no leaks. Also, I did try to return the same drag on the pinion and check it however, I really ended up just torquing the pinion nut on to ~130 -140 ft- lbs. I have had no problems with over two years and thousands of towing miles on one of them.

<



SoNic67

Explorer Addict
Joined
January 24, 2010
Messages
3,051
Reaction score
15
City, State
Newport News, VA
Year, Model & Trim Level
2001 V8 (Eddie Bauer) AWD
Thank you guys!
I did buy the Dorman Kit, it was $24 with online order and a code from retailmenot. I'll see how the original flange looks, make sense that it might have a groove after 15 years and 155k miles.
I just hope that the bearing doesn't have any play.
In one the videos the guy said not to use impact - it makes sense not to "beat" the pinion bearing with the impact, not?

<



koda2000

Explorer Addict
Joined
September 2, 2011
Messages
13,852
Reaction score
1,502
Year, Model & Trim Level
x
As far as I know, preload and pinion depth are two separate things. The preload is for the bearings, not for the pinion teeth engagement. Your (simplified) procedure is for former. Pinion depth should not be affected when only the seal is replaced.

Your are correct about the pinion depth. I was confusing the crush sleeve with the shims, which are used to set the depth.

<



SoNic67

Explorer Addict
Joined
January 24, 2010
Messages
3,051
Reaction score
15
City, State
Newport News, VA
Year, Model & Trim Level
2001 V8 (Eddie Bauer) AWD
I finished the job. Replaced the flange too with the one in Dorman kit. The original one it had a small scoring mark, not deep to hang my nail into, but still...
The seal came out very hard, the metallic surround was rusted on the differential body, so I had to go and buy a proper seal remover tool. Basically I almost broke it in pieces before it decided to move out.
The Dorman provided seal had a small bead of RTV sealant on the outer metallic side, that was nice of them.
I tighten the nut with about 20 ft-lb while "pushing" back the new flange and at some point, it stopped moving. Raised the torque set to 100 ft-lb and after not even 1/8 turn, it clicked off. I guess now it was set against the existing crush washer, with previous proper preloading.
Filled with some synthetic 75W140 to compensate for what drained over the pinion side. And what was already missing, from being leaked previously on my driveway.
Drove it around, it is more silent now (properly filled) and it free-rolls nice in N.
Hope it will be all right.
Thank you all.

<



SoNic67

Explorer Addict
Joined
January 24, 2010
Messages
3,051
Reaction score
15
City, State
Newport News, VA
Year, Model & Trim Level
2001 V8 (Eddie Bauer) AWD
Stupid question. I topped off with 75W-140 Super tech from Walmart. Full Synthetic.
Because I had lost previously fluid, it took more than expected - 1 1/2 qt.
Well, the online Walmart 75W-140 looks like this (and has listed LS applications on the specs):
Model# WM7514PL; Meets API GL-5 and MT-1, MACK GO-J, SAE J2360 and Limited Slip specifications



Mine has a different color label (violet), still Full Synth but the label says only that "Can be used to top off limited slip differentials". I didn't check fully when I used it. Well... how much means "top off"? My diff is LS and I don't hear any noises in turns. Should I worry?


<



koda2000

Explorer Addict
Joined
September 2, 2011
Messages
13,852
Reaction score
1,502
Year, Model & Trim Level
x
If your diff chatters on turns you'll need to put in an LS additive. If not, don't worry about it. Full capacity is approx 3 qts, so you were 1/2 empty (or half full, depending on whether you served in the Peace Corp or not). The LS additive is a friction modifier for the LS clutches.

<



swshawaii

Elite Explorer
Joined
April 3, 2009
Messages
9,624
Reaction score
570
City, State
Kailua-Oahu, Hawaii
Year, Model & Trim Level
'05 Sport Trac XLS (RWD)
<



SoNic67

Explorer Addict
Joined
January 24, 2010
Messages
3,051
Reaction score
15
City, State
Newport News, VA
Year, Model & Trim Level
2001 V8 (Eddie Bauer) AWD
No, I meant from the aspect of that synth gear oil that is not listed as fully LS but "top off compatible".
Should I drain some and add LS additive? I don't hear any suspicious noises in turns, I drove it in circles just to check.

It was loud before, so yes, probably the level dropped to below the pinion (shaft flange) hole - especially because it was parked on an inclined driveway, the "wrong way" (rear higher).

<



koda2000

Explorer Addict
Joined
September 2, 2011
Messages
13,852
Reaction score
1,502
Year, Model & Trim Level
x
Again, if it's quiet I wouldn't worry about it.

<
