Solved Your Stock Auto/Manual hub info - Ranger / 91-94 X

Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...News Flash...You heard it here first...

...I just got off the phone with WARN and they informed me that Randy's ring and pinion has just purchased all the tooling and he is solely going to be the one to contact for the P/N 37780...He will also be handling all the Warn axle items...

...Randy's link...
http://www.ringpinion.com/

...Warn does not know at this time if they will be making/selling all the hubs or just leave the selling to Randy's, but for now, they are focusing on making the hubs...(This part was a little confusing but time will tell)...:dunno:

...As for the exploded view of P/N 29071 hub parts I was hoping to get, they said it does not exist...

..For any parts for hubs (such as O rings, cams, etc..) that you might need, contact Warn directly as they have parts and these will not be sold elsewhere...



Join the Elite Explorers for $20 per year. Gets rid of the ads! New $5 per month "try out" option.

Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private conversations, and more. Join Today. Your support is greatly appreciated.




Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...If you are looking for parts, do not email them..:nono:

...When I talked to them on the phone he said they will help find parts by phone request as they may have them laying around...

...I previously sent an email request last week and they finally responded tonight...

..."Tbars4...Warn does not offer replacement parts for the 29071 or 29070 hubs. Give us a call if you have any questions 800-543-9276



Tom Ewing

Customer Service "

...So again, call them, don't email....:biggthump





Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...Bumpin for the new guys...:biggthump





bigredscowboy

Active Member
Joined
July 13, 2008
Messages
86
Reaction score
0
City, State
High Point, NC
Year, Model & Trim Level
2003 Ranger Edge 4.0 4x4
I didn't have any thrust spacers when I pulled my auto's off for the manual swap. Could this be the whole reason my auto's didn't work?





DeRocha

NEX Vice President
Elite Explorer
Moderator Emeritus
Joined
July 5, 2003
Messages
6,671
Reaction score
40
City, State
Brockton, MA
Year, Model & Trim Level
'93 XLT 4x4
I didn't have any thrust spacers when I pulled my auto's off for the manual swap. Could this be the whole reason my auto's didn't work?

maybe.. the thrust washers are used to locate the cam closer to the hub so the engagement fits/works better..





Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...:scratch:...I seen someone looking for this info, so here's a bump...:D





bigredscowboy

Active Member
Joined
July 13, 2008
Messages
86
Reaction score
0
City, State
High Point, NC
Year, Model & Trim Level
2003 Ranger Edge 4.0 4x4
Does anyone have these thrust spacers on their auto's? Are they metal or plastic? Seems like a pretty integral part of the system if its listed in the diagram.





Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4




Four0Sport

Jack Pewe
Elite Explorer
Joined
August 26, 2004
Messages
3,029
Reaction score
97
City, State
West Virginia
Year, Model & Trim Level
1993 2dr
this has been a great thread.. helpful to alot of members.

now i have a dumb question.. TBars you list a link for care/maintenance of auto hubs, is there any info out there on the manual hubs? I've had them on for about 3-4 yrs now and though there doesnt seem to be any damage and they still operate fine, i was curious as to what the maintenance procedure is like for the hubs.





bigredscowboy

Active Member
Joined
July 13, 2008
Messages
86
Reaction score
0
City, State
High Point, NC
Year, Model & Trim Level
2003 Ranger Edge 4.0 4x4
the warn diagram puts the spacers on the other side??? interesting





Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...I myself flush them out with tranny fluid, let them dry, and then add a real fine film of grease...Some people just flush them out...

...Most people have lost there big O ring so adding a circle of silicone where the O ring was suppose to go will keep sand, grit, and water out...;)





Four0Sport

Jack Pewe
Elite Explorer
Joined
August 26, 2004
Messages
3,029
Reaction score
97
City, State
West Virginia
Year, Model & Trim Level
1993 2dr
hmm.. i use to clean my auto hubs out with atf but never heard of it for the manual hubs.. i figured since they came from warn with a light film of grease they shouldnt be ran dry, but idk.





Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...You need to do maintenance on manual hubs also...

..Grease is like a magnet for grit such as road debris and sand and will hold it in there...If you get moisture in your hub you will get rust...You will need to flush them out...

...This is the job of the O ring that usually breaks or disappears when pulling the hub off...









Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...Then it sounds like you are in business...;)

...Now, if you found a bad/missing O ring, some debris in your hub, or your hub fell off in the dirt/sand/mud while swapping a tire, the method I described would get you back on the road as long as you had some atf handy...;)

...And before anybody says their hubs never fall off while changing a tire, :p:...I thought I was the only one who still has stock keepers on my hubs...





Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...Bumpin for the guys who are looking for hub info...;)





redrocket1468

Active Member
Joined
September 10, 2008
Messages
94
Reaction score
0
City, State
greenville
Year, Model & Trim Level
93 limited 4in.sus3in.bod
...Bumpin for the guys who are looking for hub info...;)
to make sure i got this straight if i want sronger hubs to replace my auto hubs. #1 contact randys ring and pinion for the jeep hubs. #2 contact 4wheel parts to get the kit and order 2 of them also im a little sketchy on the assembly of the new manual hubs do i need to use any of my old parts on the auto to assemble? oh yeah tbars i got those f150 coil seats from ford i forgot i had a friend who worked there got them for his cost.





Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
....You could just go with the P/N 29071 manual hubs if you don't have a locker...I've yet to grenade one before I installed my Locker in my X and I've actually broken front axle parts in my Ranger and yet to have a hub problem..:dunno:

...Once you remove your old nut and Auto hub, the only things you will keep are, your Splined washer and the c clip...

...Be sure to re-read this thread...
http://www.explorerforum.com/forums/showthread.php?p=1809056#post1809056





redrocket1468

Active Member
Joined
September 10, 2008
Messages
94
Reaction score
0
City, State
greenville
Year, Model & Trim Level
93 limited 4in.sus3in.bod
....You could just go with the P/N 29071 manual hubs if you don't have a locker...I've yet to grenade one before I installed my Locker in my X and I've actually broken front axle parts in my Ranger and yet to have a hub problem..:dunno:

...Once you remove your old nut and Auto hub, the only things you will keep are, your Splined washer and the c clip...

...Be sure to re-read this thread...
http://www.explorerforum.com/forums/showthread.php?p=1809056#post1809056
i was reading earlier on this forum that guys dislike the
29071 because they grenade them. and i am running a aussie locker in the front. im just tryin to cover my ACE if you know what i mean before summer gets here. some guys here are planning a run to gulches offroad park and im trying to prevent breaking which is impossible but still going to try.



Join the Elite Explorers for $20 per year. Gets rid of the ads! New $5 per month "try out" option.

Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private conversations, and more. Join Today. Your support is greatly appreciated.




Tbars4

Moderator Emeritus
Elite In Memoriam
Joined
March 4, 2007
Messages
26,470
Reaction score
68
City, State
anaheim hills,california
Year, Model & Trim Level
95 ranger 4x4/ 91 X 4x4
...you can break hubs or put on stronger hubs which may result in other things breaking...:dunno:...It is covered in that thread...;)

...I prefer to swap broken hubs if needed but, I have also spit out parts with stock manual hubs...
