How To Program Extra 2016 Key Fobs???

Bill #5 Explorer

Well-Known Member
Joined
February 9, 2011
Messages
1,103
Reaction score
5
City, State
Chicago Area
Year, Model & Trim Level
2016 Explorer XLT
Does anyone know how to do this? I was able to self program my 2011 Intelligent Key fobs (page #157 of the Owner's Manual), but these instructions have been removed from the 2016 owner's manual. It's a process of having all the original keys (2) in the cabin, new one in the center console, hit the door locks, hit the brake peddle, all in a special sequence.

FYI. These are the Intelligent Key fobs with the remote start function and keyless push button start.

Thanks.



Join the Elite Explorers for $20 per year. Gets rid of the ads! New $5 per month "try out" option.

Explorer Forum has probably saved you that much already, and will continue to save you money as you learn how to diagnose fix problems yourself and learn which modifications work without having to experiment on your own. Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private Conversations, and more. Join Today. Your support is greatly appreciated.




Bill #5 Explorer

Well-Known Member
Joined
February 9, 2011
Messages
1,103
Reaction score
5
City, State
Chicago Area
Year, Model & Trim Level
2016 Explorer XLT
Well, it seems like this has to be done by the dealership via computer. No more onboard ability like my 2011. Charges will be about $60 to program the fob(s).





jmr061

Well-Known Member
Joined
August 24, 2014
Messages
1,927
Reaction score
154
City, State
Wisconsin
Year, Model & Trim Level
16 Exp Sport
Really that does suck...I have to look into this....thinking about picking up a 2016 in the near future.





jmr061

Well-Known Member
Joined
August 24, 2014
Messages
1,927
Reaction score
154
City, State
Wisconsin
Year, Model & Trim Level
16 Exp Sport
Looked it up...IKTs you can program with two existing ones but not IA. Sounds like a good time to negotiate a 3rd one is during the initial vehicle purchase.





Bill #5 Explorer

Well-Known Member
Joined
February 9, 2011
Messages
1,103
Reaction score
5
City, State
Chicago Area
Year, Model & Trim Level
2016 Explorer XLT
Looked it up...IKTs you can program with two existing ones but not IA. Sounds like a good time to negotiate a 3rd one is during the initial vehicle purchase.

Correct.

Good idea on the 3rd key negotiation. An IA Key Fob is about $180 (blank key and new fob....2 separate part numbers) plus another $60-70 for programing. FYI.





Bill #5 Explorer

Well-Known Member
Joined
February 9, 2011
Messages
1,103
Reaction score
5
City, State
Chicago Area
Year, Model & Trim Level
2016 Explorer XLT
Maybe this will help future Explorer enthusiasts. Here are the part numbers:

Key Fob Only (all you really need) 164.R7989 (over $150)
Uncut key concealed blade (not really needed) 164.R7992 (over $20)
Dealership programing required, about $70





PlatinumOwner

Active Member
Joined
March 6, 2016
Messages
358
Reaction score
58
Year, Model & Trim Level
2016 Explorer Platinum
You can program IA keys with the Explorer as long as you have two admin keys. The 2018 fob works on 2016's too.

1. You must have two working IA keys
2. Insert the 1st working key into the key slot in the center console. Key ring up buttons out.
3. Push the start/stop button and wait 5 seconds.
4. Push the start/stop button.
5. Remove the 1st key and place the 2nd working key in the key slot in the center consule. Key ring up buttons out.
6. Push the start/stop button and wait 5 seconds.
7. Push the start/stop button.
8. Remove the 2nd key and place the new key to be programmed in the key slot. Key ring up buttons out.
9. Push the start/stop button and wait 5 seconds.
10. Push the start/stop button.
