Idler Pulley removal

Tony H

Explorer Addict
Joined
September 4, 2003
Messages
1,594
Reaction score
1
City, State
New York, Wading River (that's on Long Island)
Year, Model & Trim Level
'91 Eddie Bauer
Dumb question but I never had to do it before.

I want to change my Idler Pulley. Obviously the same Bolt you use to take the tension off the Belt is the bolt you need to take off to get the pulley off.

Why doesn't the bolt loosen when you use it to take the belt off?
How tight is that sucker since it doesn't loosen everytime I take the Belt off?

Is there a way to lock the Tensioner in the 'loose belt' position? I always have a tough time with the lower Bolt that holds the tensioner assy to the engine block... the Pulley is in the way.

<

Join the Elite Explorers $20 Gets rid of the ads!

Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private conversations, and more. Join Today. Your support is greatly appreciated.




Darrman

Well-Known Member
Joined
October 8, 2005
Messages
755
Reaction score
4
City, State
Waxahachie, TX
Year, Model & Trim Level
'92 Sport 4x4/2001 Sport
The bolt is reverse threaded, right-loose, left-tight. Take it and the pulley off and it makes everything else a breeze.

<



Tony H

Explorer Addict
Joined
September 4, 2003
Messages
1,594
Reaction score
1
City, State
New York, Wading River (that's on Long Island)
Year, Model & Trim Level
'91 Eddie Bauer
Reverse threaded!!!

Of course. That would make sense.

It's easiest to take the whole Tensioner assembly off the car?

I checked it last night. It feels a bit lose. Befor eI have a problem... I'll just change it. I bought the 'X' with 183K on it. It now has 256K I don't know if it was ever changed.

<



snocross1985

Explorer-less
Joined
March 25, 2003
Messages
2,668
Reaction score
0
City, State
Stratham, NH
Year, Model & Trim Level
2018 Explorer XLT
You can replace the whole tensioner for cheap, don't need to try to get the pulley off the tensioner.

<



Darrman

Well-Known Member
Joined
October 8, 2005
Messages
755
Reaction score
4
City, State
Waxahachie, TX
Year, Model & Trim Level
'92 Sport 4x4/2001 Sport
If you are going to replace just the pulley, then remove the pulley bolt only. If you are going to replace the whole tensioner assembly, then removing the pulley bolt and pulley will make it easier to get at the tensioner bolt under the pulley. It is always possible to get it out without removing the pulley, but its a pain.

<



Tony H

Explorer Addict
Joined
September 4, 2003
Messages
1,594
Reaction score
1
City, State
New York, Wading River (that's on Long Island)
Year, Model & Trim Level
'91 Eddie Bauer
Easy task. i've had the Tensioner out a few times. I was just curious about the Puller Bolt. Did it last night. Piece of cake. Through the Tensioner in a vise, two seconds on the Pulley bolt (turning it the correct direction).
Only issue was My wife just pulled in with the car so the engine was F'n Hot.

P.S. the Pulley bearing was pretty noisey, not horrible but Better do it now then have it desintergrate when I'm many miles from home.

Thanks

<
