John_Rock's 2001 Sport Trac 4x4

Well, I've been an Elite member for probably like two years. I guess it's time to put something in the Elite Registry. So here goes...

Engine: Stock 4.0L (245) SOHC SEFI V-6
Transmission: Stock Ford 5R55E 5 -Speed Automatic Overdrive
Transfer Case: Borg Warner 1354 electric shift - Gear Ratio ? Low ? 2.48:1
Steering: Stock Power, Ford - Rack and Pinion (Includes Steering Cooler) - Ratio 19.1:1 Static
Front Suspension: Superlift 4" lift
Rear Suspension: Spring over axle
Front Axle: Dana35 with a LockRight locker
Rear Axle: Ford 8.8 with a LockRight locker
Communications: Cobra 75 WX ST 40 Channel CB, Wilson 1000 antenna
Recovery Equipment: 60" Hi-Lift jack, 20' looped end tow strap.
Tires/Wheels: Super Swamper TSL/SX on 15x10 American Racing AR-767 wheels
Exterior: Performance Accessories 3" body lift. Gloria Zimmerman Rocksliders.
Interior: Leather seats, power moonroof, power rear window.
Audio: Stock CD/AM/FM radio.
Future Mods: Try to get rid of the rust before it falls apart.


Before Pic


After Pic


Purchased 6/30/2000. It was 4th of July weekend, and I took her out for some camping and
minor offroading in Big Bend National Park in 110 degree heat. I put my first scratches on her that weekend.
I was just letting her know how hard she would have to work for me.

I bought her fully loaded. I think the only option I didn't have was the audiophile stereo system and of course the hard tonneau cover wasn't available yet.

Big Bend National Park


I pretty much left her stock in appearance for over a year. Thanks to this website I learned about the KKM performance filter and installed it.



Join the Elite Explorers for $20 per year. Gets rid of the ads! New $5 per month "try out" option.

Explorer Forum has probably saved you that much already, and will continue to save you money as you learn how to diagnose fix problems yourself and learn which modifications work without having to experiment on your own. Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private Conversations, and more. Join Today. Your support is greatly appreciated.




John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
Soooooooooooooo, early Wednesday morning last week. I took her for a spin and got her stuck in some mud. Plus, I figured out that with these lift brackets the differential must be sitting too far to the passenger side, because the driver's side CV axle pulled apart on the inner CV joint. I better get that problem figured out before going wheeling again. :D




Join the Elite Explorers for $20 per year. Gets rid of the ads! New $5 per month "try out" option.

Explorer Forum has probably saved you that much already, and will continue to save you money as you learn how to diagnose fix problems yourself and learn which modifications work without having to experiment on your own. Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private Conversations, and more. Join Today. Your support is greatly appreciated.




John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
Yehey, progress this weekend.

Vacuum indented gas tank. Hmmmmmmm. Oh well.


Original fuel pump with a very dirty looking strainer.


After installing a $75 used fuel pump with a new strainer. Big improvement. Original fuel pump was putting out only 20psi.





John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
Thanks to chad551 I knew to buy Bilstein B46-1798 shocks to replace the Superlift crappy shocks. Basically a good replacement to the Superlift shocks are Jeep Cherokee front shocks.






John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
The other week(before replacing the shocks) I checked out the CV angles at full droop. They look pretty maxed out.






John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
Well I called Superlift about getting some limit straps. The package arrived on Friday. But it only contained one limit strap. :mad:

So I called them again and the CS dude said sorry and made the order to send me the 2nd one.


Yesterday I started on the task of replacing my leaf springs. I only broke 2 bolts so far. And I over heated my air compressor to get the 4 U-bolt nuts off on the driver's side.






John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
My progress today before I go to bed...

The Warrior shackles are still attached to the leaf springs because the bolts are rusted to the metal sleeve that's inside the bushings. And it's because of these deteriorated bushings that I'm replacing the springs.






Dannyboy

Other Make & Models Mod
Elite Explorer
Moderator Emeritus
Joined
February 16, 2001
Messages
5,438
Reaction score
11
City, State
43°48′48″N 91°13′59″W
Year, Model & Trim Level
91 4 do'
I actually had to set fire to rubber bushings to get them out of a leaf pack in the past. It was a little nerve racking because they were still attached to the truck but I had the torch in one hand and several items to put it out in the other.





John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
I actually had to set fire to rubber bushings to get them out of a leaf pack in the past. It was a little nerve racking because they were still attached to the truck but I had the torch in one hand and several items to put it out in the other.
Warrior shackles? Or stock shackles? After seeing this rusted bolt thing with the Warriors, I'm thinking of going back to stock shackles.





AccordRanger

Well-Known Member
Joined
June 26, 2009
Messages
270
Reaction score
1
City, State
Firestone, CO
Year, Model & Trim Level
99 Sport
I had the same problem with the stock shackles.





Turdle

Habla tortuga
Staff member
Moderator
Elite Explorer
Joined
June 16, 2003
Messages
29,580
Reaction score
1,111
City, State
Humboldt, KS
Year, Model & Trim Level
2000 Mounty
Grease the bolt and bushing sleeve up well when you re assemble it to avoid this problem later. It will help.





John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
Get up at 7pm Monday night. Go to work at 9pm. Get off at 10am Tuesday morning. Go workout at gym for 40 minutes. Go meet friends for lunch. Go home and unhook rear axle from truck. Muscle rear axle into other truck by myself. Get ready to drive 3 hours to SVO's house. Whewwwwww.






cybergasm

Explorer Addict
Joined
January 8, 2006
Messages
6,486
Reaction score
4
City, State
Humboldt Ks
Year, Model & Trim Level
1997 Mountaineer 5.0
Hercules, Hercules!!!!:D






John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
Oh yeah, while I had my head underneath the truck today I noticed a small hair line fracture in the gas tank that is leaking. :(





John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
Axle is dropped off at SVO's house. Hopefully he can get it done this weekend. Time is running out on making it to Arizona/California for my Mom's birthday(22nd) and to Truckhaven(23rd & 24th). Not to mention I ordered some badly needed body mounts from Tousley Ford today. But the parts guys says it can take 3 to 4 days for them to get from the warehouse to Tousley and then they ship them to me. :(

Ok, I pulled the leaking gas tank today. And I found a guy on Craigslist parting out a rolled 1999 Explorer. He only wants $50 for the gas tank. We will see what else I may take off his hands. :p: I'm heading there in a few hours.

Yesterday I watched/assisted SVO replace the ring and pinion and bearings on a 8.8 IRS pumpkin out of a 2007 Mustang GT500.










Blee1099

Evil Asian
Moderator Emeritus
EF Vendor
Joined
March 3, 2002
Messages
14,030
Reaction score
5
City, State
Elkridge, MD
Year, Model & Trim Level
91
Jeff wrist deep in someone's rear end.. :eek:





John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4




John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
I picked up a new/used gas tank and fuel pump for $50 before I went to work yesterday. :thumbsup:

I will prep it today and install it tomorrow.






John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
I picked up a new/used gas tank and fuel pump for $50 before I went to work yesterday. :thumbsup:

I will prep it today and install it tomorrow.
I went beyond prepping it for installation yesterday before heading to work. I got it hooked up and tested. :thumbsup::thumbsup::thumbsup:

I got my original fuel pumped installed in to the new gas tank but using the pump motor from the new tank's fuel pump assembly. So the fuel pump I installed the other month is now a spare that will work on either of my trucks. :thumbsup::thumbsup:




Join the Elite Explorers for $20 per year. Gets rid of the ads! New $5 per month "try out" option.

Explorer Forum has probably saved you that much already, and will continue to save you money as you learn how to diagnose fix problems yourself and learn which modifications work without having to experiment on your own. Elite Explorer members see no advertisements, no banner ads, no double underlined links, can add their own profile photo, upload photo attachments in all forums, and Media Gallery, create and save more private Conversations, and more. Join Today. Your support is greatly appreciated.




John_Rock

Elite In Memoriam
Joined
January 5, 2001
Messages
4,427
Reaction score
11
City, State
Houston, TX
Year, Model & Trim Level
2001 Sexy Sport Trac 4x4
New body bushings showed up yesterday. These were $98 plus shipping from Tousley Ford. I still need to buy other ones to replace, but that will happen when I have more funds to spend.
